WFJ series crusher
Description：WFJ series micro crusher is composed of main machine, auxiliary machine and electric control box. It has many functions such as air-selection, no screen, uniform particle size and so on. The production process is continuous and applicable to pharmaceutical, chemical, food Such industries crush the brittle materials.
Details
Overview
This machine is composed of host machine, auxiliary machine and electric control box. It has various functions such as air-selection, no screen, uniform particle size and so on. The production process is continuous and applicable to the pulverization of brittle materials in the pharmaceutical, chemical and food industries. .
Technical specifications
model unit WFJ-15 WFJ-18 WFJ-32 Production capacity Kg/h 10-200 20-450 60-800 Feed particle size Mm <10< td=''> <10< td=''> <15< td=''> Discharge size Mesh 80-320 80-450 80-450 Total power Kw 13.5 17.5 46 Main speed r/min 3800-6000 3800-6000 3800-4000 Dimensions Mm 4200×1200×2700 4700×1200×2900 9000×1500×3800 weight Kg 850 980 1500
